Chromium is an open-source browser project that aims to build a safer, faster, and more stable way for all users to experience surfing the web. In this step by step guide I will show you how to install Chromium on your Synology NAS with Docker & Portainer. Note: You can also install Opera, Firefox or Mullvad Browser to surf the web using your NAS.

💡Note: This guide works perfectly with the latest version of Chromium

• STEP 1

Please Support My work by Making a Donation.

• STEP 2

Install Portainer using my step by step guide. If you already have Portainer installed on your Synology NAS, skip this STEP. Attention: Make sure you have installed the latest Portainer version.

• STEP 3

Make sure you have a synology.me Wildcard Certificate. Follow my guide to get a Wildcard Certificate. If you already have a synology.me Wildcard certificate, skip this STEP.

• STEP 4

Go to Control Panel / Login Portal / Advanced Tab / click Reverse Proxy. Follow the instructions in the image below.

• STEP 5

Now click the “Create” button. Follow the instructions in the image below.

• STEP 6

After you click the Create button, the window below will open. Follow the instructions in the image below.

On the General area, set the Reverse Proxy Name description: type in Chromium. After that, add the following instructions:

Source:
Protocol: HTTPS
Hostname: chromium.yourname.synology.me
Port: 443

Check Enable HSTS

Destination:
Protocol: HTTPS
Hostname: localhost
Port: 3410

• STEP 7

On the Reverse Proxy Rules click the Custom Header tab. Click Create and then, from the drop-down menu, click WebSocket. After you click on WebSocket, two Header Names and two Values will be automatically added. Click Save. Follow the instructions in the image below.

• STEP 8

Go to Control Panel / Network / Connectivity tab/ Check Enable HTTP/2 then click Apply. Follow the instructions in the image below.

• STEP 9

Go to Control Panel / Security / Advanced tab/ Check Enable HTTP Compression then click Apply. Follow the instructions in the image below.

• STEP 10

Go to File Station and open the docker folder. Inside the docker folder, create one new folder and name it chromium. Follow the instructions in the image below.
Note: Be careful to enter only lowercase, not uppercase letters.

• STEP 11

Log into Portainer using your username and password. On the left sidebar in Portainer, click on Stacks then + Add stack. Follow the instructions in the image below.

• STEP 12

In the Name field type in chromium. Follow the instructions in the image below.

Note: Copy Paste the code below in the Portainer Stacks Web editor.

version: "3.9"
services:
  chromium:
    image: ghcr.io/linuxserver/chromium:latest
    container_name: Chromium
    hostname: chromium
    mem_limit: 3g
    shm_size: 1g
    cpu_shares: 1024
    security_opt:
      - no-new-privileges:true
      - seccomp:unconfined
    ports:
      - 3410:3001
    volumes:
      - /volume1/docker/chromium:/config:rw
    environment:
      TZ: Europe/Bucharest
      CUSTOM_USER: marius
      PASSWORD: mariushosting
      PUID: 1026
      PGID: 100
      TITLE: Chromium
    restart: on-failure:5

Note: Before you paste the code above in the Web editor area below, change the value for TZ. (Select your current Time Zone from this list.)
Note: Before you paste the code above in the Web editor area below, change the value numbers for PUID and PGID with your own values. (Follow my step by step guide on how to do this.) 1026 is my personal PUID value and 100 is my personal PGID value. You have to type in your own values.
Note: Before you paste the code above in the Web editor area below, change the value for CUSTOM_USER. Type in your own username. marius is an example for a username.
Note: Before you paste the code above in the Web editor area below, change the value for PASSWORD. Type in your own password. mariushosting is an example for a password.

• STEP 13

Scroll down on the page until you see a button named Deploy the stack. Click on it. Follow the instructions in the image below. The installation process can take up to a few minutes. It will depend on your Internet speed connection.

• STEP 14

If everything goes right, you will see the following message at the top right of your screen: “Success Stack successfully deployed“.

• STEP 15

Go back to STEP 1 or you will deal with karma 🙂

• STEP 16

Now open your browser and type in your HTTPS/SSL certificate like this https://chromium.yourname.synology.me that you have previously created at STEP 6. In my case it’s https://chromium.mariushosting.synology.me If everything goes right, you will see the Chromium Login page. Type in your own CUSTOM_USER and PASSWORD that you have previously created at STEP 12 then click Sign In. Follow the instructions in the image below.

• STEP 17

Your Chromium browser at a glance!

Enjoy Chromium!

Note: Can I run Docker on my Synology NAS? See the supported models.
Note: How to Back Up Docker Containers on your Synology NAS.
Note: Find out how to update the Chromium container with the latest image.
Note: How to Free Disk Space on Your NAS if You Run Docker.
Note: How to Schedule Start & Stop For Docker Containers.
Note: How to Activate Email Notifications.
Note: How to Add Access Control Profile on Your NAS.
Note: How to Change Docker Containers Restart Policy.
Note: How to Use Docker Containers With VPN.
Note: Convert Docker Run Into Docker Compose.
Note: How to Clean Docker.
Note: How to Clean Docker Automatically.
Note: Best Practices When Using Docker and DDNS.
Note: Some Docker Containers Need WebSocket.
Note: Find out the Best NAS Models For Docker.
Note: Activate Gmail SMTP For Docker Containers.

This post was updated on Saturday / February 24th, 2024 at 6:20 AM
